Pneumatic/Manual Stainless Ball Valves
Valworx Pneumatic/Manual combination stainless steel ball valves with integral manual override for pneumatic or manual control of air, water, oil, and other media compatible with the materials of construction.
Spring return pneumatic/manual actuators use air pressure to open the valve and springs (failsafe) to close the valve. Double acting pneumatic/manual actuators use air pressure to open the valve and air pressure to close the valve. Both types may be operated manually as well. Stroke limit function allows easy setting of limit open and limit close operation.
Advantages of pneumatic/manual actuators ball valves over other type valves may include: integral manual override, higher flow rates, higher pressures, higher temperatures, wider media compatibility, straight through flow path, reduced water hammer, and use in hazardous environments.
Rugged, hard-anodized aluminum construction with spring return or double acting options. Rack & pinion design. 316SS investment cast body, ball and stem offered in 1/4" to 4".
| Stock # | Title | Series |
Pipe Size (NPT) | Orifice Size (inches) | Max Pressure (PSI) | Body Material | Seal Material |
Price Each | Usually Ships | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Pneumatic/Manual Double Acting | |||||||||||||||||||
| 531302 | 1/4" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 1/4 | 0.45 | 1000 | Stainless | Teflon/Viton |
$328.80
|
4- 6 Weeks | ||||||||||
| 531303 | 3/8" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 3/8 | 0.49 | 1000 | Stainless | Teflon/Viton |
$328.80
|
Same Day | ||||||||||
| 531304 | 1/2" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 1/2 | 0.59 | 1000 | Stainless | Teflon/Viton |
$329.60
|
Same Day | ||||||||||
| 531306 | 3/4" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 3/4 | 0.79 | 1000 | Stainless | Teflon/Viton |
$339.20
|
4- 6 Weeks | ||||||||||
| 531308 | 1" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 1 | 1.00 | 1000 | Stainless | Teflon/Viton |
$364.80
|
4- 6 Weeks | ||||||||||
| 531310 | 1-1/4" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 1-1/4 | 1.25 | 1000 | Stainless | Teflon/Viton |
$456.80
|
4- 6 Weeks | ||||||||||
| 531312 | 1-1/2" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 1-1/2 | 1.50 | 1000 | Stainless | Teflon/Viton |
$563.20
|
Same Day | ||||||||||
| 531316 | 2" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 2 | 2.00 | 1000 | Stainless | Teflon/Viton |
$620.80
|
Same Day | ||||||||||
| 531320 | 2-1/2" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 2-1/2 | 2.56 | 800 | Stainless | Teflon/Viton |
$804.80
|
Same Day | ||||||||||
| 531324 | 3" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 3 | 3.15 | 800 | Stainless | Teflon/Viton |
$1,062.40
|
4- 6 Weeks | ||||||||||
| 531332 | 4" Pneumatic/Manual Stainless Ball Valve - Double Acting | 5313 | 4 | 3.94 | 800 | Stainless | Teflon/Viton |
$1,886.40
|
Same Day | ||||||||||
| Pneumatic/Manual Spring Return | |||||||||||||||||||
| 531402 | 1/4" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 1/4 | 0.45 | 1000 | Stainless | Teflon/Viton |
$374.40
|
4- 6 Weeks | ||||||||||
| 531403 | 3/8" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 3/8 | 0.49 | 1000 | Stainless | Teflon/Viton |
$374.40
|
4- 6 Weeks | ||||||||||
| 531404 | 1/2" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 1/2 | 0.59 | 1000 | Stainless | Teflon/Viton |
$376.00
|
4- 6 Weeks | ||||||||||
| 531406 | 3/4" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 3/4 | 0.79 | 1000 | Stainless | Teflon/Viton |
$427.20
|
Same Day | ||||||||||
| 531408 | 1" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 1 | 1.00 | 1000 | Stainless | Teflon/Viton |
$552.00
|
Same Day | ||||||||||
| 531410 | 1-1/4" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 1-1/4 | 1.25 | 1000 | Stainless | Teflon/Viton |
$561.60
|
Same Day | ||||||||||
| 531412 | 1-1/2" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 1-1/2 | 1.50 | 1000 | Stainless | Teflon/Viton |
$976.00
|
Same Day | ||||||||||
| 531416 | 2" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 2 | 2.00 | 1000 | Stainless | Teflon/Viton |
$1,033.60
|
Same Day | ||||||||||
| 531420 | 2-1/2" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 2-1/2 | 2.56 | 800 | Stainless | Teflon/Viton |
$1,168.80
|
Same Day | ||||||||||
| 531424 | 3" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 3 | 3.15 | 800 | Stainless | Teflon/Viton |
$1,490.40
|
4- 6 Weeks | ||||||||||
| 531432 | 4" Pneumatic/Manual Stainless Ball Valve - Spring Return | 5314 | 4 | 3.94 | 800 | Stainless | Teflon/Viton |
$2,044.00
|
Same Day | ||||||||||
