1" Sanitary Ball Valve, Spring Return Scotch Yoke, Tri-Clamp

Stock #: 571302A
Brand: Valworx
Series: 5713
List Price: $662.00
Price: $529.60
Buy 3 or more for $476.64 each
Usually Ships: Same Day
Free Shipping on orders over $99
Valworx 571302A air actuated stainless steel sanitary ball valves are typically used for food, beverage, pharmaceutical, personal care and pet care applications where sanitary construction is required, as well as for utility, process and corrosive environment applications where quick clamp applications are needed. Highly polished internals (8- 12 Ra finish). Dyneon PTFE ball seats and cavity fillers are standard. Triple stem seal design is live-loaded and self-adjusting, compensating for wear, pressure, and temperature fluctuations.

Ball Valve Standard Features
  • Full Port for Unrestricted Flow
  • 8- 12 Ra finish on all internal surfaces
  • Dyneon PTFE ball seats and cavity fillers
  • All materials comply with FDA and USDA requirements
  • Triple PTFE/Viton Stem Seal Design, Live Loaded
  • Standard Tri-Clamp ends for sanitary connections
  • Actuator Ready ISO5211 Direct Mounting Pad
  • All valves are tested per API 598

  • Pneumatic Actuator Standard Features
  • Extended cycle life (1 million cycles)
  • Quarter turn Scotch Yoke design
  • Highly visible valve position indicator
  • Dry or lubricated pilot air
  • Factory lubricated for normal life
  • Anodized aluminum body with epoxy-polyester coated end covers
  • Namur & ISO mounting

  • Options (see Accessories tab)
    TypeAir Actuated Sanitary Ball Valve- Spring Return
    Pipe Size ~ Tri-Clamp1" ~ 1-1/2"
    Port SizeFull port, 0.9 inch orifice, Cv 48.0
    Pressure (Max)1000 PSI WOG
    Valve Temperature Range-4 to 356 °F (-20 to 180 °C)
    Actuator Temperature Range-4 to 167 °F (-20 to 75 °C)
    Valve Body/BallASTM 316 stainless steel
    Valve StemASTM 316 stainless steel
    Internal Finish8- 12 Ra
    Ball SeatsDyneon PTFE
    Cavity fillerDyneon PTFE, encapsulated
    Stem SealsPTFE/ Viton, live loaded
    Valve Bolts/NutsASTM 304 stainless steel
    Cycle TimeApprox. 0.4- 0.6 seconds per 90° rotation
    Recommended Air Pilot Pressure58-87 PSI
    Maximum Air Pilot Pressure120 PSI
    • Direct Mount Solenoid Valves
      Direct Mount Solenoid Valve 120V 50/60Hz
      Direct Mount Solenoid Valve 120V 50/60Hz Stock #: 529200A
      Usually Ships: Same Day
      Price: $100.80
      Buy 10 or more for $90.72 each
      Quantity
    • Direct Mount Solenoid Valve 24 VDC
      Direct Mount Solenoid Valve 24 VDC Stock #: 529202A
      Usually Ships: Same Day
      Price: $100.80
      Buy 10 or more for $90.72 each
      Quantity
    • ISO DIN Plug with 16ft Cable for Solenoid Valves
      ISO DIN Plug with 16ft Cable for Solenoid Valves Stock #: 588013
      Usually Ships: Same Day
      Price: $27.08
      Buy 10 or more for $24.37 each
      Quantity
    • Limit Switch
      Actuated Valve Limit Switch IP67/NEMA 4X
      Actuated Valve Limit Switch IP67/NEMA 4X Stock #: 529910A
      Usually Ships: Same Day
      Price: $145.60
      Buy 6 or more for $131.04 each
      Quantity
    • High Temperature Mounting Kit
      High Temp/Wall Mounting Kit F05/07-14x11mm
      High Temp/Wall Mounting Kit F05/07-14x11mm Stock #: 588136
      Usually Ships: Same Day
      Price: $96.80
      Buy 6 or more for $87.12 each
      Quantity
    • Tri Clamp
      1
      1"- 1-1/2" Tri Clamp Single Pin Stock #: 579902
      Usually Ships: Same Day
      Price: $8.95
      Buy 10 or more for $8.06 each
      Quantity
