Speed control mufflers screw into exhaust ports of valves, cylinders and other air equipment to control the actuator speed, reduce noise to acceptable levels and protect the actuator/valve from dirty environments. Air flow is adjusted with a knurled knob and locking nut. Typically, two speed control mufflers are used when operating a double acting actuator and one speed control muffler used with spring return actuators.
Pipe Size: 1/8" NPT
Body: Brass
Filter Element: Sintered Bronze
Pressure Rating: 218 PSI (15 Bar)
Dimensions: 36mm length x 14mm diameter, 12mm flats
Pipe Size: 1/8" NPT
Body: Brass
Filter Element: Sintered Bronze
Pressure Rating: 218 PSI (15 Bar)
Dimensions: 36mm length x 14mm diameter, 12mm flats
