Valworx 565009 manual hand wheel gear operator fits valves with standard ISO5211 F07 mounting with 14mm square stem. Rugged construction with aluminum alloy housing, steel input shaft and worm gear with ductile iron output gear segment. Weatherproof enclosure with red visual valve position indicator. Adjustable travel stops are factory set. Standard bolts and nuts are made of SS304.
This gear operator fits Valworx ductile iron butterfly valve size 4 inch pipe (wafer or lug body).
This gear operator fits Valworx ductile iron butterfly valve size 4 inch pipe (wafer or lug body).
