Valworx 565931 manual hand wheel gear operator for high temperature applications. 316 stainless steel body, shaft and handwheel, aluminum-bronze gear drive and Viton seals offer excellent corrosion resistance. Rugged IP65 weatherproof enclosure with visual valve position indicator. Adjustable travel stops are factory set. Standard bolts and nuts are made of SS304. Fits standard ISO5211 F07/F10 mounting with 14mm square stem.
| Type | High Performance Gear Operator |
|---|---|
| Output Torque | 500Nm |
| Stem Size | 14mm |
| ISO5211 Mounting | F10 |
| Gear Ratio | 42: 1 |
| Temperature Rating | 5- 320°F (-15- 160°C) |
| Housing | 316 Stainless (CF8M) |
| Handwheel | 316 Stainless |
| Shaft | 316 Stainless |
| Seals | Viton |
| Gearing | Aluminum-Bronze |
