Valworx 540210 PVC butterfly valves are used for on-off control of water and other compatible media. Ideal for industrial apps and where NSF certified construction is required for potable/drinking water. Typical applications might include potable water, general services, industrial, process, corrosive environments, commercial plumbing, food processing and irrigation. For manual operation, combine with a hand lever or gear operator. For automation, combine with adapter plate. (See accessories tab for further details.).
PVC butterfly valves should never be used for compressed gas applications.
Industrial grade PVC butterfly valve Pressure rated 150 PSI at 73°F Polypropylene (PP) disc ANSI 150 wafer-style flange connection 316 stainless steel shaft EPDM primary liner Series 5402 NSF/ANSI/CAN 60 and NSF/ANSI 372 certified valve for potable drinking water
PVC butterfly valves should never be used for compressed gas applications.
| Type | PVC Butterfly Valve |
|---|---|
| Disc Size | 8, Cv 2135 |
| Pressure (Max) | 150 PSI at 73 °F liquid only, no air or gas (see P/T chart) |
| Temperature Range | 32 to 140 °F (0 to 60 °C) |
| Valve Body | PVC |
| Disc | Polyproplene (PP) |
| Stem | 316 Stainless Steel |
| Stem Size | 22mm |
| ISO 5211 Mount | F10 |
| Primary Liner | EPDM |
-
Price: $221.60
Buy 3 or more for $199.44 each
-
Price: $28.00
Buy 3 or more for $25.20 each
5402 Series Product Data Sheet NSF Certification to NSF/ANSI 61 Potable Drinking Water and NSF/ANSI 372 Lead FreeWe provide CAD models in virtually every format. Can't find exactly what you're looking for? Please email sales@valworx.com to request the specific files you need. Include the stock number and any accessories with your request.
