Air Actuated Brass 3-Way Ball Valves - Scotch Yoke
Valworx air actuated 3-way brass ball valves function as a T-port or L-port diverter valve. A spring return air actuator (Series 5417/5419) requires a pneumatic pilot signal to change the valve position, springs will return the valve to the normal failsafe position. Double acting air actuators (Series 5416/5418) use air pressure in both directions to change the valve position. Advantages of air actuated ball valves over other type valves may include: higher flow rates, higher pressures, higher temperatures, wider media compatibility, straight through flow path, reduced water hammer, and use in hazardous environments.
Rugged, hard-anodized aluminum construction. Explosion-proof rated to ATEX EX h IIC TX Gb/ EX h IIIC TX Db. NSF 372 / NSF 61 certified lead free and potable drinking water; 300-600 PSI pressure rated. 1/4" to 2".
Deciding between Scotch Yoke and Rack & Pinion actuators? To learn more about both designs click here.
| Stock # | Title | Series |
Pipe Size (NPT) | Orifice Size (inches) | Max Pressure (PSI) | Body Material | Seal Material |
Price Each | Usually Ships | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| T-Port ~ Double Acting | |||||||||||||||||||
| 541602 | 1/4" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 1/4 | 0.39 | 400 | LF Brass | Teflon/Viton |
$245.60
|
2- 3 Weeks | ||||||||||
| 541603 | 3/8" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 3/8 | 0.39 | 400 | LF Brass | Teflon/Viton |
$245.60
|
2- 3 Weeks | ||||||||||
| 541604 | 1/2" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 1/2 | 0.59 | 400 | LF Brass | Teflon/Viton |
$268.80
|
2- 3 Weeks | ||||||||||
| 541606 | 3/4" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 3/4 | 0.75 | 400 | LF Brass | Teflon/Viton |
$314.40
|
2- 3 Weeks | ||||||||||
| 541608 | 1" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 1 | 1.00 | 400 | LF Brass | Teflon/Viton |
$346.40
|
2- 3 Weeks | ||||||||||
| 541610 | 1-1/4" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 1-1/4 | 1.22 | 400 | LF Brass | Teflon/Viton |
$436.00
|
2- 3 Weeks | ||||||||||
| 541612 | 1-1/2" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 1-1/2 | 1.50 | 400 | LF Brass | Teflon/Viton |
$568.00
|
2- 3 Weeks | ||||||||||
| 541616 | 2" Air Actuated 3-Way Brass T-Diverter Valve, Double Acting Scotch Yoke | 5416 | 2 | 2.00 | 400 | LF Brass | Teflon/Viton |
$779.20
|
Same Day | ||||||||||
| T-Port ~ Spring Return | |||||||||||||||||||
| 541702 | 1/4" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 1/4 | 0.39 | 400 | LF Brass | Teflon/Viton |
$284.80
|
Same Day | ||||||||||
| 541703 | 3/8" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 3/8 | 0.39 | 400 | LF Brass | Teflon/Viton |
$284.80
|
Same Day | ||||||||||
| 541704 | 1/2" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 1/2 | 0.59 | 400 | LF Brass | Teflon/Viton |
$308.00
|
Same Day | ||||||||||
| 541706 | 3/4" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 3/4 | 0.75 | 400 | LF Brass | Teflon/Viton |
$355.20
|
Same Day | ||||||||||
| 541708 | 1" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 1 | 1.00 | 400 | LF Brass | Teflon/Viton |
$472.80
|
Same Day | ||||||||||
| 541710 | 1-1/4" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 1-1/4 | 1.22 | 400 | LF Brass | Teflon/Viton |
$574.40
|
Same Day | ||||||||||
| 541712 | 1-1/2" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 1-1/2 | 1.50 | 400 | LF Brass | Teflon/Viton |
$726.40
|
Same Day | ||||||||||
| 541716 | 2" Air Actuated 3-Way Brass T-Diverter Valve, Spring Return Scotch Yoke | 5417 | 2 | 2.00 | 400 | LF Brass | Teflon/Viton |
$984.00
|
Same Day | ||||||||||
| L-Port ~ Double Acting | |||||||||||||||||||
| 541802 | 1/4" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 1/4 | 0.39 | 400 | LF Brass | Teflon/Viton |
$245.60
|
2- 3 Weeks | ||||||||||
| 541803 | 3/8" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 3/8 | 0.39 | 400 | LF Brass | Teflon/Viton |
$245.60
|
2- 3 Weeks | ||||||||||
| 541804 | 1/2" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 1/2 | 0.59 | 400 | LF Brass | Teflon/Viton |
$268.80
|
2- 3 Weeks | ||||||||||
| 541806 | 3/4" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 3/4 | 0.75 | 400 | LF Brass | Teflon/Viton |
$314.40
|
2- 3 Weeks | ||||||||||
| 541808 | 1" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 1 | 1.00 | 400 | LF Brass | Teflon/Viton |
$346.40
|
2- 3 Weeks | ||||||||||
| 541810 | 1-1/4" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 1-1/4 | 1.22 | 400 | LF Brass | Teflon/Viton |
$436.00
|
2- 3 Weeks | ||||||||||
| 541812 | 1-1/2" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 1-1/2 | 1.50 | 400 | LF Brass | Teflon/Viton |
$568.00
|
2- 3 Weeks | ||||||||||
| 541816 | 2" Air Actuated 3-Way Brass L-Diverter Valve, Double Acting Scotch Yoke | 5418 | 2 | 2.00 | 400 | LF Brass | Teflon/Viton |
$779.20
|
Same Day | ||||||||||
| L-Port ~ Spring Return | |||||||||||||||||||
| 541902 | 1/4" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 1/4 | 0.39 | 400 | LF Brass | Teflon/Viton |
$284.80
|
Same Day | ||||||||||
| 541903 | 3/8" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 3/8 | 0.39 | 400 | LF Brass | Teflon/Viton |
$284.80
|
Same Day | ||||||||||
| 541904 | 1/2" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 1/2 | 0.59 | 400 | LF Brass | Teflon/Viton |
$308.00
|
Same Day | ||||||||||
| 541906 | 3/4" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 3/4 | 0.75 | 400 | LF Brass | Teflon/Viton |
$355.20
|
Same Day | ||||||||||
| 541908 | 1" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 1 | 1.00 | 400 | LF Brass | Teflon/Viton |
$472.80
|
Same Day | ||||||||||
| 541910 | 1-1/4" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 1-1/4 | 1.22 | 400 | LF Brass | Teflon/Viton |
$574.40
|
Same Day | ||||||||||
| 541912 | 1-1/2" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 1-1/2 | 1.50 | 400 | LF Brass | Teflon/Viton |
$726.40
|
Same Day | ||||||||||
| 541916 | 2" Air Actuated 3-Way Brass L-diverter Valve, Spring Return Scotch Yoke | 5419 | 2 | 2.00 | 400 | LF Brass | Teflon/Viton |
$984.00
|
Same Day | ||||||||||
