Air Actuated Flanged Ball Valve - All Stainless
Valworx 5351/5352 series air actuated ANSI 150lb. stainless flanged ball valve with stainless steel Rack & Pinion pneumatic actuator. Dual-certified low-emission/fire safe valve. All 316 stainless construction for outstanding corrosion resistance. For On/Off control of water, air, oil and gas and other compatible media.
Spring return air actuators (series 5352) require a pneumatic pilot signal to change the valve position. Springs will return the valve to the normal failsafe position. Double acting air actuators (series 5351) use air pressure to open the valve and air pressure to close the valve.
| Stock # | Title | Series | Pipe Size (NPT) | Orifice Size (inches) | Max Pressure (PSI) | Body Material | Seal Material |
Price Each | Usually Ships | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Double Acting | |||||||||||||||||||
| 535108 | 1" All Stainless 150# Flanged Ball Valve- Double Acting | 5351 | 1 | 1.00 | 275 | Stainless | Braided Graphite/Viton |
$642.40 |
Same Day | ||||||||||
| 535112 | 1 1/2" All Stainless 150# Flanged Ball Valve- Double Acting | 5351 | 1-1/2 | 1.50 | 275 | Stainless | Braided Graphite/Viton |
$811.20 |
Same Day | ||||||||||
| 535116 | 2" All Stainless 150# Flanged Ball Valve- Double Acting | 5351 | 2 | 2.00 | 275 | Stainless | Braided Graphite/Viton |
$1,252.80 |
Same Day | ||||||||||
| 535124 | 3" All Stainless 150# Flanged Ball Valve- Double Acting | 5351 | 3 | 3.20 | 275 | Stainless | Braided Graphite/Viton |
$2,068.80 |
2- 3 Weeks | ||||||||||
| 535132 | 4" All Stainless 150# Flanged Ball Valve- Double Acting | 5351 | 4 | 4.00 | 275 | Stainless | Braided Graphite/Viton |
$2,672.00 |
2- 3 Weeks | ||||||||||
| Spring Return | |||||||||||||||||||
| 535208 | 1" All Stainless 150# Flanged Ball Valve- Spring Return | 5352 | 1 | 1.00 | 275 | Stainless | Braided Graphite/Viton |
$689.60 |
Same Day | ||||||||||
| 535212 | 1 1/2" All Stainless 150# Flanged Ball Valve- Spring Return | 5352 | 1-1/2 | 1.50 | 275 | Stainless | Braided Graphite/Viton |
$1,029.60 |
Same Day | ||||||||||
| 535216 | 2" All Stainless 150# Flanged Ball Valve- Spring Return | 5352 | 2 | 2.00 | 275 | Stainless | Braided Graphite/Viton |
$1,272.80 |
Same Day | ||||||||||
| 535224 | 3" All Stainless 150# Flanged Ball Valve- Spring Return | 5352 | 3 | 3.20 | 275 | Stainless | Braided Graphite/Viton |
$2,321.60 |
2- 3 Weeks | ||||||||||
| 535232 | 4" All Stainless 150# Flanged Ball Valve- Spring Return | 5352 | 4 | 4.00 | 275 | Stainless | Braided Graphite/Viton |
$3,251.20 |
2- 3 Weeks | ||||||||||
