Air Actuated Stainless Ball Valves - Scotch Yoke
Valworx air actuated stainless steel ball valve for On/Off control of air, water, oil, and other media compatible with the materials of construction. Spring return air actuators use air pressure to open the valve and springs (failsafe) to close the valve. Double acting air actuators use air pressure to open the valve and air pressure to close the valve.
Advantages of air actuated ball valves over other type valves may include: higher flow rates, higher pressures, higher temperatures, wider media compatibility, straight through flow path, reduced water hammer, and use in hazardous environments.
Rugged, hard-anodized aluminum construction. Explosion-proof rated to ATEX EX h IIC TX Gb/ EX h IIIC TX Db. 316SS investment cast body, ball and stem offered in 1/4" to 4".
Deciding between Scotch Yoke and Rack & Pinion actuators? To learn more about both designs click here.
| Stock # | Title | Series |
Pipe Size (NPT) | Orifice Size (inches) | Max Pressure (PSI) | Body Material | Seal Material |
Price Each | Usually Ships | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Double Acting | |||||||||||||||||||
| 553502A | 1/4" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 1/4 | 0.45 | 1000 | Stainless | Teflon/Viton |
$301.29
|
6- 8 Weeks | ||||||||||
| 553503A | 3/8" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 3/8 | 0.49 | 1000 | Stainless | Teflon/Viton |
$301.29
|
Same Day | ||||||||||
| 553504A | 1/2" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 1/2 | 0.59 | 1000 | Stainless | Teflon/Viton |
$302.29
|
Same Day | ||||||||||
| 553506A | 3/4" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 3/4 | 0.79 | 1000 | Stainless | Teflon/Viton |
$311.20
|
Same Day | ||||||||||
| 553508A | 1" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 1 | 1.00 | 1000 | Stainless | Teflon/Viton |
$337.68
|
Same Day | ||||||||||
| 553510A | 1 1/4" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 1 1/4 | 1.25 | 1000 | Stainless | Teflon/Viton |
$410.11
|
Same Day | ||||||||||
| 553512A | 1-1/2" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 1 1/2 | 1.50 | 1000 | Stainless | Teflon/Viton |
$505.14
|
Same Day | ||||||||||
| 553516A | 2" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 2 | 2.00 | 1000 | Stainless | Teflon/Viton |
$558.98
|
Same Day | ||||||||||
| 553520A | 2 1/2" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 2 1/2 | 2.56 | 800 | Stainless | Teflon/Viton |
$732.22
|
Same Day | ||||||||||
| 553524A | 3" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 3 | 3.15 | 800 | Stainless | Teflon/Viton |
$945.20
|
6- 8 Weeks | ||||||||||
| 553532A | 4" Air Actuated Stainless Ball Valve - Double Acting Scotch Yoke | 5535 | 4 | 3.94 | 800 | Stainless | Teflon/Viton |
$1,700.59
|
Same Day | ||||||||||
| Spring Return | |||||||||||||||||||
| 553602A | 1/4" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 1/4 | 0.45 | 1000 | Stainless | Teflon/Viton |
$346.50
|
6- 8 Weeks | ||||||||||
| 553603A | 3/8" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 3/8 | 0.49 | 1000 | Stainless | Teflon/Viton |
$346.50
|
Same Day | ||||||||||
| 553604A | 1/2" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 1/2 | 0.59 | 1000 | Stainless | Teflon/Viton |
$347.50
|
Same Day | ||||||||||
| 553606A | 3/4" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 3/4 | 0.79 | 1000 | Stainless | Teflon/Viton |
$389.42
|
Same Day | ||||||||||
| 553608A | 1" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 1 | 1.00 | 1000 | Stainless | Teflon/Viton |
$506.74
|
Same Day | ||||||||||
| 553610A | 1 1/4" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 1 1/4 | 1.25 | 1000 | Stainless | Teflon/Viton |
$534.79
|
Same Day | ||||||||||
| 553612A | 1-1/2" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 1 1/2 | 1.50 | 1000 | Stainless | Teflon/Viton |
$685.40
|
Same Day | ||||||||||
| 553616A | 2" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 2 | 2.00 | 1000 | Stainless | Teflon/Viton |
$981.66
|
Same Day | ||||||||||
| 553620A | 2 1/2" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 2 1/2 | 2.56 | 800 | Stainless | Teflon/Viton |
$993.28
|
Same Day | ||||||||||
| 553624A | 3" Air Actuated Stainless Ball Valve -Spring Return Scotch Yoke | 5536 | 3 | 3.15 | 800 | Stainless | Teflon/Viton |
$1,316.53
|
6- 8 Weeks | ||||||||||
| 553632A | 4" Air Actuated Stainless Ball Valve - Spring Return Scotch Yoke | 5536 | 4 | 3.94 | 800 | Stainless | Teflon/Viton |
$1,833.85
|
Same Day | ||||||||||
