Home/Valve Accessories/Valve Mounting Brackets & Adapters

Valve Mounting Brackets & Adapters

Valve Mounting Brackets & Adapters
valworx
High temp/wall mounting kits are used to increase the allowable media operating temperature of an actuated valve assembly. The stainless steel bracket and drive coupler mount between a valve and actuator providing additional air cooling. Conforms to international standard ISO5211/DIN3337 and is available in sizes F03 to F10. In addition, bracket can be used to mount an actuated valve assembly to a customer supplied channel, angle iron or other custom bracket. Square adapters install over the stem on ball valves and butterfly valves to increase the size to match the output female drive size of electric and air actuators. PVC Valve Mounting Kits are used for easy mounting of Valworx 5402/5510/5514 series PVC butterfly & ball valves.
Stock # Title Series Description Price Each Usually Ships
High Temp/Wall Mounting Kits
588128 High Temp/Wall Mounting Kit F03/05-9x9mm 5881 High Temp/Wall Mounting Kit F03/05-9x9mm
$67.20
Same Day
588129 High Temp/Wall Mounting Kit F03/05-11x9mm 5881 High Temp/Wall Mounting Kit F03/05-11x9mm
$68.00
Same Day
588130 High Temp/Wall Mounting Kit F03/05-11x11mm 5881 High Temp/Wall Mounting Kit F03/05-11x11mm
$68.80
Same Day
588131 High Temp/Wall Mounting Kit F03/05-14x9mm 5881 High Temp/Wall Mounting Kit F03/05-14x9mm
$72.00
Same Day
588132 High Temp/Wall Mounting Kit F03/05-14x11mm 5881 High Temp/Wall Mounting Kit F03/05-14x11mm
$72.00
Same Day
588133 High Temp/Wall Mounting Kit F03/05-14x14mm 5881 High Temp/Wall Mounting Kit F03/05-14x14mm
$75.20
Same Day
588135 High Temp/Wall Mounting Kit F05/07-11x11mm 5881 High Temp/Wall Mounting Kit F05/07-11x11mm
$76.80
Same Day
588136 High Temp/Wall Mounting Kit F05/07-14x11mm 5881 High Temp/Wall Mounting Kit F05/07-14x11mm
$80.00
Same Day
588137 High Temp/Wall Mounting Kit F05/07-14x14mm 5881 High Temp/Wall Mounting Kit F05/07-14x14mm
$83.20
Same Day
588138 High Temp/Wall Mounting Kit F05/07-17x17mm 5881 High Temp/Wall Mounting Kit F05/07-17x17mm
$84.00
Same Day
588139 High Temp/Wall Mounting Kit F07/10-14x14mm 5881 High Temp/Wall Mounting Kit F07/10-14x14mm
$86.40
Same Day
588141 High Temp/Wall Mounting Kit F07/10-17x17mm 5881 High Temp/Wall Mounting Kit F07/10-17x17mm
$87.20
Same Day
Square Adapters
581109 Square Adapter 11mm x 9mm 5800 Square Adapter 11mm x 9mm
$10.11
Same Day
581109A Double Square Adapter 11mm x 9mm 5800 Double Square Adapter 11mm x 9mm
$23.21
Same Day
581409A Square Adapter 14mm x 9mm Extra Long 5800 Square Adapter 14mm x 9mm Extra Long
$14.44
Same Day
581411 Square Adapter 14mm x 11mm 5800 Square Adapter 14mm x 11mm
$11.96
Same Day
581711 Square Adapter 17mm x 11mm 5800 Square Adapter 17mm x 11mm
$11.84
Same Day
581714 Square Adapter 17mm x 14mm 5800 Square Adapter 17mm x 14mm
$11.97
Same Day
582217 Square Adapter 22mm x 17mm 5800 Square Adapter 22mm x 17mm
$17.41
Same Day
582722 Square Adapter 27mm x 22mm 5800 Square Adapter 27mm x 22mm
$20.88
Same Day
PVC Valve / Actuator Mounting Kits
551208 PVC Valve/ Actuator Mounting Kit 1/2", F03/F04-11mm 5512 PVC Valve/Actuator Mounting Kit 1/2" F03/F04-11mm
$54.40
Same Day
551208A 551208A - PVC Valve/Actuator Mounting Kit 1/2", F03/F04/F05 5512 PVC Valve/Actuator Mounting Kit 1/2" F03/F04/F05-11mm
$74.40
Same Day
551212 PVC Valve/ Actuator Mounting Kit 3/4", F03/F05-11mm 5512 PVC Valve/Actuator Mounting Kit 3/4" F03/F05-11mm
$56.80
Same Day
551216 PVC Valve/ Actuator Mounting Kit 1", F03/F05-11mm 5512 PVC Valve/Actuator Mounting Kit 1" F03/F05-11mm
$68.00
Same Day
551220 PVC Valve/ Actuator Mounting Kit 1-1/4", F05/F07-11mm 5512 PVC Valve/Actuator Mounting Kit 1-1/4" F05/F07-11mm
$68.00
Same Day
551221 PVC Valve/ Actuator Mounting Kit 1-1/4", F05/F07-14mm 5512 PVC Valve/Actuator Mounting Kit 1-1/4" F05/F07-14mm
$68.00
Same Day
551224 PVC Ball Valve/ Actuator Mounting Kit 1-1/2", F05/F07-11mm 5512 PVC Valve/Actuator Mounting Kit 1-1/2" F05/F07-11mm
$69.60
Same Day
551225 PVC Ball Valve/ Actuator Mounting Kit 1-1/2", F05/F07-14mm 5512 PVC Ball Valve/Actuator Mounting Kit 1-1/2" F05/F07-14mm
$69.60
Same Day
551232 PVC Valve/ Actuator Mounting Kit 2", F05/F07-11mm 5512 PVC Valve/Actuator Mounting Kit 2" F05/F07-11mm
$69.60
Same Day
551233 PVC Valve/ Actuator Mounting Kit 2", F05/F07-14mm 5512 PVC Valve/Actuator Mounting Kit 2" F05/F07-14mm
$69.60
Same Day
551248 PVC Valve/ Actuator Mounting Kit, F07 5512 PVC Valve/Actuator Mounting Kit F07
$64.00
Same Day
551249 PVC Valve/ Actuator Mounting Adapter 8", F10 5512 PVC Valve/Actuator Mounting Adapter 8" F10
$69.60
Same Day
PVC Valve Wall or Panel Mounting Kits
551250 PVC Valve Wall or Panel Mounting Kit 1/2" to 1" 5512 PVC Valve Wall or Panel Mounting Kit 1/2" to 1"
$23.20
Same Day
551251 PVC Valve Wall or Panel Mounting Kit 1-1/4" to 2" 5512 PVC Valve Wall or Panel Mounting Kit 1-1/4" to 2"
$24.80
Same Day
