Electric Actuated 3-Way Sanitary Ball Valves - Multi-Voltage

Valworx

Valworx multi-voltage electric actuated 3-way sanitary ball valves are typically used for food, beverage, pharmaceutical, personal care and pet care applications where 3-A sanitary construction is required, as well as for utility, process and corrosive environment applications where quick clamp applications are needed. Highly polished internals (8- 12 Ra finish) and virgin PTFE cavity-filled ball seats are standard.

Note: Tri-Clamp size is NOT determined by the OD of the end cap. Refer to chart below for Tri-Clamp size.

Battery Safe Return (BSR) option powers the valve closed (Normally Closed) in the event of a loss of external power. Can also be set to Normally Open.

Stock #	Title	Series	Pipe Size ~ Tri-Clamp (inches)	Orifice Size (inches)	Max Pressure (PSI)	Body Material	Seal Materials	90° Cycle Time (sec)	Voltage	Price Each	Usually Ships
T-Port ~ 24 to 240 Volt
572400	1/2" Sanitary Ball Valve, T-Port, 24-240V, Tri-Clamp	5724	1/2 ~ 3/4	0.4	1000	Stainless	Virgin PTFE/Viton	9	24-240V	$892.80	1- 3 Days
572401	3/4" Sanitary Ball Valve, T-Port, 24-240V, Tri-Clamp	5724	3/4 ~ 3/4	0.6	1000	Stainless	Virgin PTFE/Viton	9	24-240V	$926.40	Same Day
572402	1" Sanitary Ball Valve, T-Port, 24-240V, Tri-Clamp	5724	1 ~ 1-1/2	0.9	1000	Stainless	Virgin PTFE/Viton	13	24-240V	$1,284.00	Same Day
572403	1-1/2" Sanitary Ball Valve, T-Port, 24-240V, Tri-Clamp	5724	1-1/2 ~ 1-1/2	1.4	1000	Stainless	Virgin PTFE/Viton	29	24-240V	$1,597.60	Same Day
572404	2" Sanitary Ball Valve, T-Port, 24-240V, Tri-Clamp	5724	2 ~ 2	1.9	1000	Stainless	Virgin PTFE/Viton	29	24-240V	$1,851.20	Same Day
572405	2-1/2" Sanitary Ball Valve, T-Port, 24-240V, Tri-Clamp	5724	2-1/2 ~ 2-1/2	2.4	1000	Stainless	Virgin PTFE/Viton	58	24-240V	$3,832.00	1- 3 Days
572406	3" Sanitary Ball Valve, T-Port, 24-240V, Tri-Clamp	5724	3 ~ 3	2.9	1000	Stainless	Virgin PTFE/Viton	58	24-240V	$4,172.80	1- 3 Days
L-Port ~ 24 to 240 Volt
573400	1/2" Sanitary Ball Valve, L-Port, 24-240V, Tri-Clamp	5734	1/2 ~ 3/4	0.4	1000	Stainless	Virgin PTFE/Viton	9	24-240V	$892.80	Same Day
573401	3/4" Sanitary Ball Valve, L-Port, 24-240V, Tri-Clamp	5734	3/4 ~ 3/4	0.6	1000	Stainless	Virgin PTFE/Viton	9	24-240V	$926.40	5- 7 Days
573402	1" Sanitary Ball Valve, L-Port, 24-240V, Tri-Clamp	5734	1 ~ 1-1/2	0.9	1000	Stainless	Virgin PTFE/Viton	13	24-240V	$1,284.00	Same Day
573403	1-1/2" Sanitary Ball Valve, L-Port, 24-240V, Tri-Clamp	5734	1-1/2 ~ 1-1/2	1.4	1000	Stainless	Virgin PTFE/Viton	29	24-240V	$1,597.60	Same Day
573404	2" Sanitary Ball Valve, L-Port, 24-240V, Tri-Clamp	5734	2 ~ 2	1.9	1000	Stainless	Virgin PTFE/Viton	29	24-240V	$1,851.20	Same Day
573405	2-1/2" Sanitary Ball Valve, L-Port, 24-240V, Tri-Clamp	5734	2-1/2 ~ 2-1/2	2.4	1000	Stainless	Virgin PTFE/Viton	58	24-240V	$3,832.00	1- 3 Days
573406	3" Sanitary Ball Valve, L-Port, 24-240V, Tri-Clamp	5734	3 ~ 3	2.9	1000	Stainless	Virgin PTFE/Viton	58	24-240V	$4,172.80	1-3 Days
