Electric Actuated Sanitary Ball Valves - Positioner
Valworx electric actuated sanitary ball valves with EPS-positioner are typically used for food, beverage, pharmaceutical, personal care and pet care applications where sanitary construction is required, as well as for utility, process and corrosive environment applications where quick clamp applications are needed. Highly polished internals (8- 12 Ra finish) and Dyneon® PTFE cavity-filled ball seats are standard.
Modulating flow control via 24VDC or 110VAC, CSA listed per UL429 and CSA C22.2.
Note: Tri-Clamp size is NOT determined by the OD of the end cap. Refer to chart below for Tri-Clamp size.
| Stock # | Title | Series |
Pipe Size ~ Tri-Clamp (inches) | Orifice Size (inches) | Max Pressure (PSI) | Body Material | Seal Materials | 90° Cycle Time (sec) | Voltage | Price Each | Usually Ships | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 110 VAC with EPS Positioner 4-20mA Input | |||||||||||||||||||
| 570600C | 1/2" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 1/2 ~ 3/4 | 0.4 | 1000 | Stainless | Dyneon PTFE/Viton | 21 | AC 110 |
$1,148.80
|
Same Day | ||||||||
| 570601C | 3/4" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 3/4 ~ 3/4 | 0.6 | 1000 | Stainless | Dyneon PTFE/Viton | 21 | AC 110 |
$1,160.00
|
9- 16 Weeks | ||||||||
| 570602C | 1" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 1 ~ 1-1/2 | 0.9 | 1000 | Stainless | Dyneon PTFE/Viton | 21 | AC 110 |
$1,174.40
|
4- 6 Weeks | ||||||||
| 570603C | 1-1/2" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 1-1/2 ~ 1-1/2 | 1.4 | 1000 | Stainless | Dyneon PTFE/Viton | 21 | AC 110 |
$1,285.60
|
Same Day | ||||||||
| 570604C | 2" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 2 ~ 2 | 1.9 | 1000 | Stainless | Dyneon PTFE/Viton | 21 | AC 110 |
$1,388.00
|
Same Day | ||||||||
| 570605C | 2-1/2" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 2-1/2 ~ 2-1/2 | 2.4 | 800 | Stainless | Dyneon PTFE/Viton | 30 | AC 110 |
$2,284.80
|
Same Day | ||||||||
| 570606C | 3" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 3 ~ 3 | 2.9 | 800 | Stainless | Dyneon PTFE/Viton | 30 | AC 110 |
$2,612.80
|
Same Day | ||||||||
| 570607C | 4" Sanitary Ball Valve, 110 VAC EPS-Positioner, Tri-Clamp | 5706 | 4 ~ 4 | 3.8 | 800 | Stainless | Dyneon PTFE/Viton | 30 | AC 110 |
$2,883.20
|
4- 6 Weeks | ||||||||
| 24 VDC with EPS Positioner 4-20 mA Input | |||||||||||||||||||
| 570800C | 1/2" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 1/2 ~ 3/4 | 0.4 | 1000 | Stainless | Dyneon PTFE/Viton | 25 | DC 24 |
$1,236.00
|
Same Day | ||||||||
| 570801C | 3/4" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 3/4 ~ 3/4 | 0.6 | 1000 | Stainless | Dyneon PTFE/Viton | 25 | DC 24 |
$1,248.00
|
9- 16 Weeks | ||||||||
| 570802C | 1" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 1 ~ 1-1/2 | 0.9 | 1000 | Stainless | Dyneon PTFE/Viton | 25 | DC 24 |
$1,268.00
|
4- 6 Weeks | ||||||||
| 570803C | 1-1/2" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 1-1/2 ~ 1-1/2 | 1.4 | 1000 | Stainless | Dyneon PTFE/Viton | 25 | DC 24 |
$1,373.60
|
Same Day | ||||||||
| 570804C | 2" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 2 ~ 2 | 1.9 | 1000 | Stainless | Dyneon PTFE/Viton | 25 | DC 24 |
$1,475.20
|
Same Day | ||||||||
| 570805C | 2-1/2" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 2-1/2 ~ 2-1/2 | 2.4 | 800 | Stainless | Dyneon PTFE/Viton | 30 | DC 24 |
$2,336.00
|
2- 3 Weeks | ||||||||
| 570806C | 3" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 3 ~ 3 | 2.9 | 800 | Stainless | Dyneon PTFE/Viton | 30 | DC 24 |
$2,688.00
|
2- 3 Weeks | ||||||||
| 570807C | 4" Sanitary Ball Valve, 24 VDC EPS-Positioner, Tri-Clamp | 5708 | 4 ~ 4 | 3.8 | 800 | Stainless | Dyneon PTFE/Viton | 30 | DC 24 |
$2,928.00
|
2- 3 Weeks | ||||||||
